IGS-10080MFT

IGS-10080MFT

Industrial 8 100/1000X SFP + 2-Port 10/100/1000T Managed Switch (-40~75 degrees C)

O Planet IGS-10080MFT faz parte dos grupos dos Ethernet Industrial, Switch Industrial Gerenciável, L2+ Ring Managed Gigabit Ethernet Switch e dispõe dos seguintes recursos:

  • IPv6-Management
  • -40-degree-~75-degree
  • giga
  • SFP
  • Redundant Power
  • IP-Code 30
Hardware Specification
SFP/mini-GBIC Slots 8 100/1000Base-SX/LX mini-GBIC SFP slots
Copper Ports 2 10/100/1000Base-T Ethernet interface
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking
Throughput (packet per second) 14.8Mpps
Address Table 8K entries, automatic source address learning and ageing
Flow Control IEEE 802.3x Pause Frame for Full-Duplex. Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button < 5 sec: System reboot
> 5 sec: Factory Default
ESD Protection 6KV DC
EFT Protection 6KV DC
Enclosure IP30 Aluminum Metal Case
Installation DIN Rail Kit and Wall Mount Kit
Alarm One relay output for power fail
Alarm Relay current carry ability: 1A @ DC 24V
LED Indicators System:
 Power 1 (Green)
 Power 2 (Green)
 Fault Alarm (Green)
 Ring (Green) *
 R.O. (Green) *
Per 10/100/1000T RJ-45 Ports:
 1000 (Green)
 10/100, LNK/ACT (Orange)
Per SFP Interface:
 1000 LNK/ACT(Green)
 100 LNK/ACT (Orange)
Dimension (W x D x H) 72 x 107 x 152mm
Weight 1036g
Power Requirement DC 12 to 48V, AC 24V Power Adapter
Power Consumption 13.92 Watts / 47.76BTU (Full loading)
Layer 2 function
Basic Management Interfaces Web Browser, Remote Telnet, SNMP v1, v2c
Secure Management Interface SSH, SSL, SNMP v3
Port configuration Port disable/enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Auto-Detection / Forced 100/1000Mbps SFP Fiber transceiver speed
Flow Control disable / enable
Power saving mode control
Port Status Display each port’s speed duplex mode, link status, Flow control status, Auto negotiation status, trunk status
Port Mirroring TX / RX / Both
Many to 1 monitor
E.R.P.S. Ring * Recovery time <20ms
VLAN 802.1Q Tagged Based VLAN, up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN
MAC-Based VLAN
Protocol-Based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs
Link Aggregation IEEE 802.3ad LACP / Static Trunk
Supports 5 groups of 10-Port trunk
QoS Traffic classification based, Strict priority and WRR
8-Level priority for switching
 - Port Number
 - 802.1p priority
 - 802.1Q VLAN tag
 - DSCP field in IP Packet
IGMP Snooping IGMP (v1/v2/V3) Snooping, up to 255 multicast Groups
IGMP Querier mode support
MLD Snooping MLD (v1/v2) Snooping, up to 255 multicast Groups
MLD Querier mode support
Access Control List IP-Based ACL / MAC-Based ACL
Up to 256 entries
Bandwidth Control Per port bandwidth control
 Ingress: 500Kb~1000Mbps
 Egress: 500Kb~1000Mbps
SNMP MIBs RFC-1213 MIB-II
RFC-2236 IGMPv2
RFC-2710 MLDv1
RFC-3376 IGMPv3
RFC-2879 RMON 1, 2, 3, 9
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2819 RMON MIB (Group 1, 2, 3 and 9)
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
RFC3411 SNMP-Frameworks-MIB
IEEE 802.1X PAE
IF-MIB
LLDP
MAU-MIB
Standards Conformance
Regulation Compliance FCC Part 15 Class A, CE
Stability Testing IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Standards Compliance IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX / 100Base-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
Environment
Operating
Temperature:-40 ~ 75 degree C
Relative Humidity:5 ~ 95 % (non-condensing)
Storage
Temperature:-40 ~ 75 degree C
Relative Humidity:5 ~ 95 % (non-condensing)
* Remark: function to expect in future
